Multi-layer industrial steel structure building structure, suitable for shopping malls and commercial purposes

Multi-layer industrial steel structure building structure, suitable for shopping malls and commercial purposes
Prefabricated steel structure warehouses provide a reliable, efficient, and customizable solution for businesses and organizations in need of storage and logistics facilities. Their durability, cost-effectiveness, and flexibility make them a popular choice for a wide range of industries.
+8619063521259
sales02@bksteelstrcture.com
Contact us

Product Details

Products

PrSpecification

Specifications:
main steel frameH section steel beam and columns, painted or hot dip galvanizing, galvanized C section or steel pipe
Secondary frameHot dip galvanized C purlin, steel bracing , tie bar , knee brace , edge cover etc.
Roof panelSteel sheet, Alum-Zinc sheet , Alumnium sheet, EPS sandwich panel,glass fiber sandwich panel,rock wool sandwich panel,and PU sandwich panel etc.
Wall panelSandwich Panel or Corrugated Steel Sheet etc.
Tie RodCircular Steel Tube
BraceRound Bar
Knee BraceAngle Steel
Roof GutterColor Steel Sheet, Alum-zinc sheet, Gal. sheet, Stainless steel
Drawings & Quotation:
(1) Customized design is welcomed. We will quote for you promptly.
(2) In order to give you an exactly quotation and drawings, please let us know the length, width, eave height and local weather.
The above is for reference only,the specific required material components according to customer needs.


Material list
Project sampleSteel structure warehouse
Building sizeSuch as 78*30*8.5 m/ customized
Main steel structure
Steel columnH(300-550)*200*6*10 mm , steel Q345
Steel beamH(300-550)*180*6*8 mm, H 300*180*6*8 mm,steel Q345
Second steel structure
Roof purlineC180*75*50*2.5 mm
Wall purlineC180*75*50*2.5 mm
Cross support20 round steel bar, steel Q 235
Column bracing20 round steel bar, steel Q 235
Angle braceL 50*4 Angle steel , steel Q 235
Tie bar89*3 mm, steel Q235
Roof and wall panel
Roof panel50/80/100/150/200 mm sandwich panel (EPS, PU, Rock wool, Glass wool)
Wall panel50/80/100/150/200 mm sandwich panel (EPS, PU, Rock wool, Glass wool)
Rolling up doorAutomatic rolling up door
Single wing doorSandwich panel door
WindowAluminum/ PVC sliding window with single glass
FittingsGlass adhesive, self-tapping screw, etc
Other fittings
EmbeddedM 24 steel Q 235, process
Intensive boltGrade 10.9
Ordinary boltGrade 4.85

1744960115771752421830049794

1744960115771752421834256386

Technical Parameters
1Wind ResistanceGrade 12
2Earthquake Resistance8 Degree
3Live load of corridor2.0 kn square meter
4External and internal wall heat transmission coefficient0.35 k cal /m2hc
5Roof live board0.5 kn square meter
6Suitable Temperature-50 ℃~+50℃
7Bearing load150 kg square meter
8Life spanOver 50 years




Certificate

Products

  • 重守
  • 资信
  • 质服
  • 诚信经营示范单位
  • 诚信企业家
  • 行业
  • 经理人
  • 立信单位
  • 信用
  • 供应商
  • 未标题-3
  • 2023年12月25日北科营业执照副本
  • beike
  • 2024年3月21日北科新建筑施工企业安全生产许可证_00
  • 2024年3月21日北科新建筑业企业资质证书_00
  • 1
  • 聊城北科新材料科技有限公司-QES(1)(1)(2)-4
  • 聊城北科新材料科技有限公司-QES(1)(1)(2)-2

Factory Display

Products

Factory interior
Workstation operation details
  • 厂区细部3
  • 厂区细部2
  • 厂区细部1
  • 厂区细部6
  • 厂区细部5
  • 厂区细部4
  • 工位作业细部8
  • 工位作业细部7
  • 工位作业细部6
  • 工位作业细部5
  • 工位作业细部4
  • 工位作业细部11
  • 工位作业细部9
  • 工位作业细部10

Packing & Delivery

Products

  • H737982c83cbc4a3f8e6906b878ebb229N
  • H62e7887630294d119fc2199937396643A
  • Hb4dac970519247c98f0e8159444a0b864
  • Hb94675af5325432e9f41c1544074f61ce
  • H8abe21a2bf8c46cbb4ccc0681534a703a
  • H3b722173c2e34ddfa9ba14e9aabe26eaU

FAQ

Products

Q:

Q: What one-stop services and technical support can we provide for overseas steel structure projects?

A:
A: We provide one-stop services for overseas steel structure projects with support from our own physical factory and experienced engineering team. Our service covers technical communication, drawing review, project evaluation, customized solutions, detailing coordination, production planning, fabrication, quality inspection, export packing, shipment coordination, and delivery follow-up. We do not only manufacture steel components. We also help solve technical and execution issues before production, including structural optimization, connection detailing, layout improvement, fabrication feasibility review, and coordination between drawings and manufacturing. With our own factory, we can control quality, lead time, and component consistency more directly, giving overseas buyers stronger confidence in customized production and reliable delivery.
Q:

Q: Why choose us rather than other suppliers?

A:
A: We stand out through our one-stop service system, reliable product quality, and proven overseas project experience. From technical communication, drawing review, and customized solutions to detailing, fabrication, quality inspection, export packing, shipment coordination, and delivery follow-up, we support the whole project process. With our own physical factory, we can control production quality, schedule, and component consistency more directly. Our experienced engineering team helps solve technical and execution issues before production, reducing errors and improving efficiency. We have also participated in overseas energy, bridge, and industrial projects, giving us stronger practical capability in international project delivery and on-site cooperation.
Q:

Q: What products do we supply?

A:
A: We supply a wide range of steel structure products, including steel workshops, warehouses, industrial buildings, bridges, Bailey bridges, grid structures, villas, cold storage buildings, livestock buildings, and other customized steel components. We place strong emphasis on product quality, manufacturing accuracy, and delivery reliability. With our own factory and professional engineering team, we can also provide project-based customized solutions according to drawings, technical requirements, application scenarios, and site conditions, so the products better fit real project needs.
Q:

Q: How can we ensure quality?

A:
A: We ensure quality through strong engineering, factory control, and proven overseas project experience. Our technical team uses PKPM, 3D3S, Midas, SAP2000, Tekla, and BIM for design, detailing, and production coordination, helping solve technical issues before fabrication starts. We have our own manufacturing base of over 200 mu with annual output above 200,000 tons, supported by Grade II general contracting, Grade I steel structure contracting, and certified quality, safety, and environmental systems. We have also delivered overseas projects in the Philippines, Pakistan, Nepal, and Ethiopia, covering power plants, bridges, and industrial buildings, which strengthens our practical ability in fabrication, export delivery, and on-site cooperation.
Q:

Q: Who are we?

A:
A: We are a steel structure company based in Shandong, China, supported by our own factory, professional engineering team, and complete export service system. We focus on overseas steel structure projects and provide one-stop services including technical consultation, drawing review, customized solutions, detailing, fabrication, quality control, export packing, shipment coordination, and delivery support. Our products have been exported to Southeast Asia, the Middle East, North America, Central America, East Asia, and South Asia. With strong manufacturing capacity and project experience, we can provide more reliable quality and delivery. We sincerely welcome overseas buyers and partners to visit our factory for cooperation and project discussion.
